AIPS T-Stück VSH SudoPress VCE130G XL 108xRp 3/4x108, ES, EPDM-O-Rg, M-Kontur
AIPS T-Stück VSH SudoPress VCE130G XL
108 x Rp 3/4 x 108, Edelstahl, EPDM-O-Ring, M-Kontur
108 x Rp 3/4 x 108, Edelstahl, EPDM-O-Ring, M-Kontur
- Werkstoff Anschluss 1
- Edelstahl
- Rohraußendurchmesser Anschluss 3 [mm]
- 108 mm
- Werkstoff Anschluss 2
- Edelstahl
- Anschluss 1
- Pressmuffe
- DVGW-Siegel für Wasser
- nein
- Oberflächenschutz Anschluss 1
- unbehandelt
- Werkstoffgüte Anschluss 1
- Edelstahl 316 L (1.4404)
- Werkstoff Anschlusses 3
- Edelstahl
- Werkstoffgüte Anschluss 3
- Edelstahl 316 L (1.4404)
- VdS-geprüft
- nein
- Nenndurchmesser Anschluss 3
- DN 100
- Oberflächenschutz Anschluss 2
- unbehandelt
- Nenndurchmesser Anschluss 1
- DN 100
- Systemgebunden
- ja
- Reduzierend
- ja
- Grad [°]
- 90 °
- Konturcode Verbindung 1
- M
- DVGW-Siegel für Gas
- nein
- Werkstoffgüte Anschluss 2
- Edelstahl 316 L (1.4404)
- Modell
- SP6130GVM
- Oberflächenbehandlung Anschluss 1
- unbehandelt
- Produktklasse
- T-Stück Rohrsystem
- Oberflächenschutz Anschluss 3
- unbehandelt
- UBA-Positivliste
- ja
- Mediumtemperatur (Dauerbetrieb) [°C]
- -35 - 135 °C
- Anschluss 3
- Pressmuffe
- Nenndurchmesser Anschluss 2
- 3/4 Zoll
- Anschluss 2
- Innengewinde zylindrisch BSPT-Rp (ISO 7-1 / EN 10226-1)
- Serie
- VSH SudoPress
- Oberflächenbehandlung Anschluss 2
- unbehandelt
- Rohraußendurchmesser Anschluss 1 [mm]
- 108 mm
- Oberflächenbehandlung Anschluss 3
- unbehandelt
- Rohraußendurchmesser Anschluss 2 [mm]
- 26,9 mm
